Function£º
·Designed with a set of vertically movable, four wheel driven muted intelligent
massage hands
·Designed with emulation massage methods of shiatsu, kneading, flapping,
knocking, simultaneous kneading and flapping
·Set with the shoulder automatic detection and location
·Set with characterizedauto massage function: ache-improving, comfort, ease, fast
improving experience massage, upper body, lower body six kinds of automatic.
·Set with memory set on function M1 and M2
·Manual massage for the upper body with three options, fixed, partial and overall
massage, with five levels of speed adjustable. in the state of flapping, shiatsu and
knocking, the width between the two kneading balls is adjustable with three
Levels: wide, medium and narrow. On partial and fixed point, the massage hands
can move up and down to adjust the massage point accurately.
·Air pressure massage function with three modes: full body air pressure, arms
(upper arm set with 4 air bags, arm set with 8 air bags), leg set with 16 air bags,
three intensity optional.
·Leg designed with roller massage function at the bottom of foot, two pairs of
papillae on toe root rotating massage; on the arch and heel mastoid skin scraping
massage.
·On upper arm has two grades width adjustment function(When you adjust to the
last grade, to push into the arm about a gear distance then lose your hand and
arm device will automatically reset, and so on)in order to adapt to the different
shoulder breadth of users.
·Back heating function: carbon fi ber far infrared heat source.
·The footrest use double step less extended to suit for different body heights.
·Backrest frame down slides used technology to deviate from the wall by keeping
zero space, reach the maximum space saving
·Leg lifting adjusting, the backrest frame lifting adjusting and automatic lay down
mode adjustment function
·L shape back track fitting curves of the body, can realize the zero gravity when
back down
Name and function of components Function
1.Head cushion
2.Upper arm air bag components
3.Manual controller pocket
4.Arm air bag components
5.Seat cushion
6.Leg rest frame
7.Foot rest frame
8.Calf stop sealing plate
9.Back rest pad
10.Armrest decoration
11.Armrest
12.Side cover
13.Back cover
14.Manual controller
15.Drive box cover
16.Safety switch
17.Base caster
18.Power cord and plug
19.Power socket
20.Fuse box
21.Power switch
22.Remote control wire socket
14
13
17
19 20 21 22
15
16
18
1
2
3
5
6
9
7
11
12
8
10
4
FUSE: T5AL 220V ON/OFF CONTROLLER JACK
POWER
Rated voltage: 110-120V~ 60Hz
220-240V~ 50Hz/60Hz
Rated power input:150W
Rated time: 20Min
Safety structure: Class I
